The 4U distribution is designed to meet the demand for compact and flexible DC
power solutions. It is based on building blocks and has a variety of configurations
depending on power, controller, battery section and load section. Pluggable battery breakers and DIN mounted load breakers ensures easy configurability as well as “in field” replacement. The power system has two controller options, Smartpack2 or Smartpack S which both has all the functionality required in present and future applications.
Input
Max input AC Voltage
305 VAC
Mains configuration
230VAC Single phase;230VAC 3 phase (Δ);230/400VAC 3 phase (Y)
DC Output
Battery Distribution
Breaker rating up to
250 A
DC Load Distribution
Breaker positions up to
20
Breaker rating up to
125 A
Other
Operating temperature
-40 - 70 °C
Dimensions
Dimensions WxHxD (mm)
482 x 380 x 311 mm
Dimensions WxHxD (inch)
19 x 14,9 x 12,2 "
